Enter the value of an impedance into the stack.

You can do things to the Z impedance alone, or combine the Z and A impedances in various ways.

The impedances each consist of two terms: resistance and reactance. NetCalc also displays a complex admittance register, labeled Y, which is also used as a general display register. Note: In Ian White's NETCALC program the first and second elements of the stack are called X and Y. The Z and A registers are the first and second elements of a stack. NetCalc displays a number of complex impedance registers, labeled A, Z, P, Z0, N, and rho. The web widget can be run in most browsers. The Yahoo! Widget uses the Yahoo! Widget Engine and runs on Mac OS X and Windows. Two versions of NetCalc are currently available, a Yahoo! Widget The L-section code in NetCalc is based on a PERL program by Claude Frantz. NETCALC can be executed on various versions of the Microsoft Windows Operating System. RF Impedance Calculator by Ian White, GM3SEK.

NetCalc - An RF Impedance Calculator NetCalc - an RF Impedance Calculator
